Courtesy: NIcholas Strasser MD
Vanderbilt Unviersity, Nashville, Tennessee, US
Overview and Background
-
Anterior tibial tendon ruptures are rare and not well documented.
-
Treatment strategies can be tricky due to the limited literature.
-
The speaker has experience with external ankle bracing, which is used in rehabilitation.
Anatomy Review
-
The anterior tibial tendon originates from the lateral tibia and runs under the extensor retinaculum.
-
It inserts into the medial cuneiform and base of the first metatarsal.
-
Innervated by the deep fibular (peroneal) nerve.
-
Blood supply includes the anterior tibial artery (proximal) and medial tarsal artery (distal).
-
The rupture often occurs in a “watershed” area with less vascular supply.
Function of the Tendon
-
Main function is during about 1/3 of the gait cycle.
-
In swing phase: helps dorsiflex the foot for toe clearance.
-
In stance phase: eccentrically lowers the foot to the ground during heel strike.
-
Provides dorsiflexion and inversion.
-
Dysfunction may mimic foot drop and lead to tripping or foot slapping.
Pathophysiology and Biomechanics
-
Ruptures often occur in tendons with pre-existing tendinopathy.
-
Tendon behaves like a spring during gait, storing and releasing energy.
-
Muscle fibers don’t change length as much—tendon stretch accounts for motion.
Epidemiology and Presentation
-
Much less common than Achilles tendon ruptures.
-
Typical patient: active male in 60s–70s, sometimes linked to sports like pickleball.
-
Common patient remarks:
-
“My foot slaps when I walk.”
-
“I trip over my foot.”
-
“It’s weak, not painful.”
-
“Feels unstable.”
-
“I catch my toe when barefoot.”
-
Clinical Diagnosis
-
Often misdiagnosed as an ankle sprain.
-
Important to test ankle dorsiflexion in all “ankle sprain” patients.
-
Must check contralateral side for comparison.
-
EHL (extensor hallucis longus) may compensate, masking the rupture.
-
Gait may show compensatory big toe lift (steppage gait).
Imaging
-
MRI is useful—look for distal rupture signs (e.g., “Slytherin sign” or snake-head shape).
-
May show associated arthritis or osteophytes irritating the tendon.
Treatment Options
-
Non-operative treatment:
-
Best for elderly or non-surgical candidates.
-
Use of drop foot braces can be surprisingly effective.
-
No need to operate on all patients.
-
Concern exists about delaying surgery: may lead to muscle atrophy or worsen function.
-
-
Surgical repair:
-
Preferred for acute traumatic ruptures.
-
Timing and patient selection are key.
-
Tendon transfers may be needed in some cases.
-
-
Key Points Summary:
Early Repair (<6 weeks):
-
Not always ideal — tendon may be too diseased to heal well.
-
Even early, tendon reapproximation can be difficult.
-
Standard approach: Anteromedial incision; repair with a Krackow stitch technique.
-
If the tendon quality is good, early repair is reasonable.
Techniques for Primary Repair:
-
Insertional ruptures can use:
-
Suture anchors
-
Teno-deses screws
-
Endobuttons (looped through the medial cuneiform)
-
-
Goal: regain tendon length — often challenging.
Outcomes & Expectations:
-
Only small case series available; no large comparative studies.
-
Patients generally do well but rarely regain full strength.
-
Residual weakness common — especially in toe extension (EHL still firing).
-
Important to counsel patients pre-op: “never quite normal”.
Case Example (Traumatic Laceration):
-
Female in her 50s with ATT laceration and retraction.
-
Successful acute repair after separate incision for proximal stump.
-
Also repaired EHL, EDL.
-
Result: functional recovery, but minor imbalance/clawing of toes — typical due to altered length-tension relationship.
If You Can’t Reapproximate Tendon:
-
Z-lengthening or free sliding tendon graft using the patient’s own tendon.
-
Maintains native anatomy and avoids donor site morbidity.
-
Downside: altered tendon biomechanics.
-
Gait analysis: good function but not symmetrical — about 50% dorsiflexion compared to the unaffected side.
Chronic Cases: Tendon Transfer Options:
-
Most use EHL or EDL transfers.
-
EHL transfer:
-
In-phase transfer.
-
Weak (ATT provides ~80% of dorsiflexion strength).
-
Risks: big toe droop.
-
May require IP joint fusion to stabilize toe.
-
Fixation methods: interference screw, drill hole + loop back.
-
Set repair in 10° dorsiflexion.
-
Often combined with gastrocnemius recession to reduce posterior tension.
-
-
EDL transfer:
-
Weaves EDL into ATT.
-
Distal slips tenodesed to EDB.
-
Rarely used; mostly case reports.
-
Allograft/Autograft Reconstruction:
-
Often used when:
-
Large gaps or chronic ruptures.
-
Extensor tendons not available.
-
-
Needs viable ATT muscle for function.
-
Consider MRI of proximal leg to evaluate muscle quality.
-
Similar approach to rotator cuff tear evaluation.
-
-
May also achieve tenodesis effect (passive support) even with minimal muscle contraction.
Surgical Technique Overview:
1. Graft Options:
-
Allografts are usually preferred due to availability and avoidance of donor site morbidity.
-
Hamstring autografts may be used in revisions or when allografts aren’t viable.
2. Graft Fixation Strategy:
-
Use of Pulvertaft weave and distal bio-tenodesis for strong fixation.
-
If using a longer graft (allograft/autograft), a drill hole in the medial cuneiform can help anchor it.
3. Graft Material:
-
Preference for Arthrex FlexBand Twist (5mm x 30mm).
-
Benefits: strong suture-holding capacity, spring-like behavior, durable under tension.
-
4. Incision and Tissue Management:
-
Two-incision approach:
-
Distal incision to identify and tag the ATT stump.
-
Proximal incision above the extensor retinaculum, preserving overlying soft tissue to reduce wound complications.
-
-
Avoid disruption of the extensor retinaculum, which improves healing and lowers morbidity.
5. Surgical Steps:
-
Secure graft distally into medial cuneiform.
-
Attach native ATT to graft at distal end.
-
Pass graft under retinaculum to proximal ATT stump.
-
Max dorsiflex the ankle and tension graft proximally before fixation.
-
Reinforce with tendon-to-tendon suture repair, potentially with a Z-lengthening if tension is too high.
Post-Op Rehab Protocol:
0–4 Weeks:
-
Splint or cast in maximum dorsiflexion.
-
Emphasis on no plantar flexion or stretch—staff instructed not to let foot hang.
4–8 Weeks:
-
Transition to a CAM boot.
-
Begin passive dorsiflexion, active plantarflexion, progressive weight-bearing.
8+ Weeks:
-
Transition to brace or similar:
-
Can be locked in dorsiflexion.
-
Avoids limb length discrepancy.
-
-
Continue physical therapy to regain strength and function.
Clinical Outcomes:
-
Early results show good dorsiflexion strength return.
-
Incisions heal well; tendon glides appropriately.
-
Avoids drawbacks of autografts (donor site issues), while achieving strong functional restoration.
-
-
